Our Single Stage Sump Pump has been meticulously designed for Sump applications, ensuring efficiency in drainage tasks. This Vertical Immersion Centrifugal Pump efficiently evacuates collected fluids, and boasts robust construction and versatile capabilities suited to diverse industrial processes. Manufactured from high-quality materials such as Stainless Steel, this pump handles industrial fluids including clean and dirty water, and chemicals. With an immersion depth of 4m, extendable upon request, and a customisable base plate, this pump ensures adaptability to various operational setups. Additionally, equipped with grease-lubricated bearings, it offers reliable performance, with an optional ATEX-rating ensuring safe operation in hazardous environments.
Typical applications for our Single Stage Sump Pump:
Product summary
• Can handle fluids containing suspended solids and fibrous content
• Several impeller options including; closed, semi open and vortex
• Large solids passage capability
• Back pull out design to ensure quick and easy maintenance
• Maximum fluid temperature of 110°C
• Independent pump and motor shafts
• Available in cast iron, cast steel and other materials upon request
• Suction and discharge flanges conform to EN 1092-2 / PN 16. Flanges according to EN 1092-1 / PN 16 for steel and stainless steel casings. If required, ANSI/ASME flanges can be supplied.
• Gland packing or mechanical seal options available
• Single phase and three phase 50hz / 60hz motors. IP55 as standard.
• ATEX version upon request
• Independent certification is available upon request
• Low NPSH
• All impellers are balanced according to ISO 1940 class 6.3
• Long coupled with baseplate
• Bearings are normally life time grease lubricated bearings, although certain sizes are oil lubricated
| Capacity | Up to 1590 m³/hr |
| Head | Up to 275 Mtr. |
| Discharge Size | 25 mm to 300 mm. |
| Temperature | -10°C to +110°C |
| Speed | Up to 3500 rpm |
| Pressure | Up to 30 kg/cm² |
| M.O.C. | Ductile Iron, CF8M (316) SS, CD4MCuN and Alloy 20 materials available |
